| Welcome to the Power of Three! |
The IMI Sensors division has three groups with dedicated and experienced staff waiting to exceed your expectations. This customer oriented organization makes it easier for you to find the best product and get technical support as fast as possible. Please call our dedicated hotline at any time; we are looking forward to helping you be successful.
IMI industrial sensors are used to spot imbalance, bearing faults and misalignment by measuring machine vibration, providing early fault diagnosis thus reducing downtime. Our vast product line interfaces directly with data acquisition equipment including online systems and handheld data collectors.
IMI offers a full line of piezoelectric accelerometers, velocity sensors, 4-20 mA vibration transmitters, switches, relays, cables, displays and accessories. Virtually all of our products are certified for use in hazardous areas through CSA and ATEX. We are proud to state that 100% of our products are made in the USA and backed by our Total Customer Satisfaction policy.
|
Low-cost Industrial ICP® Accelerometer
Model 603C01
General purpose, industrial, ceramic shear ICP® accel, 100 mV/g, 0.5 to 10k Hz, top exit, 2-pin conn.
- Sensitivity: (±10%) 100 mV/g (10.2 mV/(m/s²))
- Frequency Range: (±3dB) 30 to 600000 cpm (0.5 to 10000 Hz)
- Measurement Range: ±50 g (±490 m/s²)
- Electrical Connector: 2-Pin MIL-C-5015
Related Products
Also available in:
Vibration Switch
Model 686B01
USB programmable electronic vibration switch with 2-pin MIL-C-5015 connector
The 686B01 Smart Vibration Switch is a low cost verstile and fully USB Programable electronic vibration switch that replaces unreliable mechanical vibration switches. It is also a significantly lower cost alternative for many electronic vibration switch applications
- Relay: (Type) SPST, Form A or B MOSFET
- Power Required: 24 to 240 V DC/AC 50/60 Hz
Industrial ICP® Accelerometer
Model HT602D01
High temperature 602D01
- Sensitivity: (±10%) 100 mV/g (10.2 mV/(m/s²))
- Frequency Range: (±3dB) 48 to 480000 cpm (0.8 to 8000 Hz)
- Measurement Range: ±50 g (±490 m/s²)
- Electrical Connector: 2-Pin MIL-C-5015
4-20 mA Output Velocity Sensor
Model 640B01
Industrial vibration sensor, 4 to 20 mA output, 0 to 1 in/sec pk, 3 to 1k Hz, top exit, 2-pin conn.
- Measurement Range: 0.0 to 1 in/sec pk (0.0 to 25.4 mm/s pk)
- Output: 4-20 mA
- Frequency Range: (±10%) 180 to 60000 cpm (3 to 1000 Hz)
Related Products
Swiveler® Industrial ICP® Accelerometer
Model 607A11
Low profile industrial ICP® accel, 100 mV/g, 0.5 to 10k Hz, side exit, 10-ft integral cable & swiveler base
US patent number 6.435.902
- Sensitivity: (±15%) 100 mV/g (10.2 mV/(m/s²))
- Frequency Range: (±3dB) 30 to 600000 cpm (0.5 to 10000 Hz)
- Measurement Range: ±50 g (±490 m/s²)
- Mounting: Stud
- Electrical Connector: Molded Integral Cable
Related Products
Low-cost Industrial ICP® Accelerometer
Model 608A11/030BZ
Low cost, general purpose, industrial ceramic shear ICP® accel., 100 mV/g, top exit, 30-ft integral cable
Low-cost industrial accelerometer with integral 30 ft. cable to blunt termination, 100 mV/g, general purpose, submersible, ceramic shear ICP®, 0.5 to 10k Hz, top exit
Product Data Sheet
- Sensitivity: (±15%) 100 mV/g (10.2 mV/(m/s²))
- Frequency Range: (±3dB) 30 to 600000 cpm (0.5 to 10000 Hz)
- Measurement Range: ±50 g (±490 m/s²)
- Mounting: Stud
- Electrical Connector: Molded Integral Cable
Reciprocating Machinery Protector
Model EX649A71
Loop Powered 4-20 mA Output Reciprocating Machinery Protector (RMP) (CSA/ ATEX Approved)
Provides early warning of faults and mechanical looseness in reciprocating compressors, eliminates false trips, outputs exclusive Reciprocating Fault Index (RFI), trends peak acceleration before alarm event occurs, hermetically sealed, 4-20 mA loop powered, field programmable with USB interface (Model 070A82- sold separately) CSA and ATEX approved, supplied with explosion proof conduit elbow
Reciprocating Machinery Protector Data Sheet
- Output: 4-20 mA
- Machinery RPM Range: 150 to 4800 cpm (2.5 to 80 Hz)
- Sampling Time: 0.2 to 6.4 sec
- Temperature Range: -40 to 212 °F (-40 to 100 °C)
- Excitation Voltage: 15 to 30 VDC
IN-LINE ICP TO 4-20 MA OUTPUT VELOCITY CONVERTER
Model 682A09
Vibration transmitter (for use w/ICP® sensor), 4 to 20 mA output, 3 to 10k Hz
- Output Range: 4 to 20 mA
- Measurement Range: 0.0 to 1.0 in/sec pk (0.0 to 25.4 mm/s pk)
Bearing Fault Detector
Model 682A05
Bearing Fault Detector, DIN rail mount vibration transmitter (for use w/ICP® sensor), dual 4 to 20 mA outputs for overall and peak vibration
Provides early warning of bearing and gear faults, detects impacting associated with spalling, cracking, and lubrication problems, outputs dual 4-20 mA signals for overall vibration and peak acceleration, provides excitation for ICP® accelerometers.
Product Data Sheet
- Output Range: (Linear Scale) 4 to 20 mA
- Measurement Range: (Fault Detector) 50 g
- Din Rail Mount: 1.38 in (35 mm)
Related Products
Loop Powered, Current Output, Industrial Displacement Sensor
Model 653A01
4-20 mA displacement transmitter
- Measurement Range: 2 to 40 mil pk - pk (0.05 to 1.02 mm pk - pk)
- Output: 4-20 mA
- Frequency Range: (±3dB) 90 to 18000 cpm (1.5 to 300 Hz)
Also available in:
Electronic Vibration Switch
Model 685B0001A13
Electronic vibration switch
685B series electronic vibration switch with internal sensor, 0-1.5 ips scale factor, 85-245 Vac power, 10A Form C relays, single 1/2" NPT conduit hub, CSA approved.
- Measurement Range: 0 to 1.5 in/sec pk (0 to 38.1 mm/s pk)
- Enclosure: Internal and Remote Reset
- Cable Input: Single 1/2 in. NPT Conduit Hub
- Relay: (Alert) 10 A, 245 VAC/30 VDC, Form C
- Relay: (Alarm) 10 A, 245 VAC/30 VDC, Form C
- Power Required: 85-245 VAC 50/60 Hz
|
|
