Vibration Switch
Model 686B01

USB programmable electronic vibration switch with 2-pin MIL-C-5015 connector

The 686B01 Smart Vibration Switch is a low cost versatile and fully USB Programmable electronic vibration switch that replaces unreliable mechanical vibration switches. It is also a significantly lower cost alternative for many electronic vibration switch applications. For current version, see: Model 686C01

  • Relay: (Type) SPST, Form A or B MOSFET
  • Power Required: 24 to 240 V DC/AC 50/60 Hz


SpecificationsDrawingProduct ManualPictureDownloads
PERFORMANCE ENGLISH SI
Alarm Threshold (±10 %) 0.25 to 5 in/sec pk
4.5 to 90 mm/s rms [2]
Frequency Range (±3 dB) 420 to 60 kcpm
7 to 1,000 Hz
Hysteresis (% < Alarm Threshold) 3; 6; or 10 %
3; 6; or 10 % [2]
Residual Vibration Level (Reference) Dependent or Independent
Dependent or Independent [2]
Residual Vibration Level (% Alarm Threshold) 1 to 40 %
1 to 40 % [2]
MAVT (Sets Alarm Threshold to 2X actual vibration) Enabled or Disabled
Enabled or Disabled [2]
Transverse Sensitivity <7 %
<7 %
Power On Delay (±1 sec) 3 or 20 sec
3 or 20 sec [2]
Startup Delay (±1 sec or 1 min) (Time) 1 to 60 sec or 1 to 30 min
1 to 60 sec or 1 to 30 min [2]
Startup Delay (x Alarm Threshold) x2; x4; x8; Blocked
x2; x4; x8; Blocked [2]
Startup Delay (Active) Enabled or Disabled
Enabled or Disabled [2]
Operational Delay (±1 sec) 1 to 60 sec
1 to 60 sec [2]
Relay SPST, Form A or B MOSFET
SPST, Form A or B MOSFET
Relay Latching / Non-Latching
Latching / Non-Latching [2]
Relay Normally Open / Closed
Normally Open / Closed [2]
ENVIRONMENTAL
Temperature Range (Operating) -40 to 185 °F
-40 to 85 °C
Temperature Range (Storage) -40 to 257 °F
-40 to 125 °C
Overload Limit (Shock) 5,000 g pk
49,050 m/s2 pk
Enclosure Rating IP68
IP68
ELECTRICAL
Power Required 24 to 240 V DC/AC 50/60 Hz
24 to 240 V DC/AC 50/60 Hz
Current Rating (Relay Closed) 500 mA
500 mA
Leak Current (Relay Open) ≤ 1 mA
≤ 1 mA
Electrical Isolation (Case) >108 Ohm
>108 Ohm
PHYSICAL
Size - Hex 1.25 in
1.25 in
Size - Height 2.6 in
66 mm
Weight 5.2 oz
148 gm
Mounting Torque 3 to 5 ft-lb
4 to 7 Nm
Mounting Thread 1/4-28 Female
1/4-28 Female
Sensing Element (Internal) Piezoelectric Accelerometer
Piezoelectric Accelerometer
Housing Material Stainless Steel
Stainless Steel
Sealing Welded Hermetic
Welded Hermetic
Electrical Connector 2-Pin MIL-C-5015
2-Pin MIL-C-5015
Electrical Connection Position Top
Top
SUPPLIED ACCESSORIES:
Model 081A41 Mounting stud 1/4-28 socket head set screw brass tip stainless steel 5/8" long (1)
OPTIONAL VERSIONS
EX - Hazardous Area Approval- contact factory for specific approvals
Current Rating (Relay Closed) 100 mA
Hazardous Area Approval Cl I, Div 2, Groups A, B, C, D; Ex nL IICT3, AEx nA IICT3
Power Required 10 to 30 VDC
Relay 10 to 30 VDC, 100 mA
M - Metric Mount
Supplied Accessory : Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1)

All specifications are at room temperature unless otherwise specified.
NOTES:
[1] See PCB Declaration of Conformance PS096 for details.
[2] USB Programmable - See configuration sheet supplied with switch for exact setting.




View Spec Sheet: 686B01_B.pdf
